Hand trucks & appliance trolleys

Order code:

HTBNB

Frame dimensions (HxW):

1290 x 370 mm

Finish:

Powder-coated RHS and structural steel

Features:

The axle is specifically designed for load-bearing and easy-tilting, doing the heavy work for you.

Multi-grip loop handle.

Baseplate (LxWxD):

430 x 240 x 9 mm

Trolley weight:

22 kg

Load capacity:

300 kg

Load support:

Full height, flat surface RHS frame for secure support of double box stacks.
For example, you can carry 13 cartons of beer safely with this trolley instead of 7 cartons with most others, saving valuable time.

Wheels:

265 mm diametre x 70 mm wide tubeless black pneumatic on steel rim (Fallshaw).

Order code:

HTAR

Frame dimensions (HxW):

1400 x 370 mm

Finish:

Powder-coated RHS and structural steel

Features:

The axle is specifically designed for load-bearing and easy-tilting, doing the heavy work for you.

Adjustable drum holding hook.

Ergonomic hand grips.

Baseplate (LxWxD):

430 x 240 x 9 mm

Trolley weight:

20 kg

Load capacity:

300 kg

Load support:

Curved support with 60 mm set back. Adjustable drum holding hook or optional tub holding hook. If the hook is not required, simply rotate the mounting collar sideways out of the way.

Wheels:

265 mm diametre x 70 mm wide tubeless black pneumatic on steel rim (Fallshaw).

Order code:

HTSP

Frame dimensions (HxW):

1560 x 430 mm

Finish:

Powder-coated RHS and structural steel

Features:

The axle is specifically designed for load-bearing and easy-tilting, doing the heavy work for you.

Two hand grip levels.

Baseplate (LxWxD):

430 x 240 x 9 mm

Trolley weight:

28 kg

Load capacity:

300 kg

Load support:

Flat

Wheels:

320 mm diametre x 70 mm wide tubeless black pneumatic on steel rim (Fallshaw).

Order code:

Claxmobile

Upper tray capacity:

20 kg

Order code:

RuXXacJ

Height open:

1250 mm

Height folded:

870 mm

Thickness folded:

120 mm

Shoe:

570 mm wide x 345 mm deep

Load capacity:

250 kg

Width open/assembled:

655 mm

Width folded:

570 mm

Unit weight:

12.8 kg

Construction:

Steel and Aluminium tube and glass reinforced plastics

Wheels:

220 mm diametre x 70 mm wide, pneumatic wheels with roller bearings

Order code:

RuXXacB

Height open:

1030 mm

Height folded:

685 mm

Thickness folded:

55 mm

Shoe (WxD):

490 x 250 mm

Load capacity:

125 kg

Width open/assembled:

575 mm

Width folded:

490 mm

Unit weight:

5.4 kg

Construction:

Steel and Aluminium tube and glass reinforced plastics

Wheels:

200 mm diametre x 40 mm wide, solid grey non marking rubber with roller bearings

Order code:

TSHTSB

Frame dimensions (HxW):

1330 x 510 mm

Features:

Easy lean back frame.

Baseplate:

Extra-wide reinforced steel shoe tailor-made for beverage cartons.

Trolley weight:

22 kg

Load capacity:

300 kg

Load support:

Trolley lays back at rest position aiding tilting during use.

Wheels:

250 mm diameter puncture proof pneumatic wheels supplied as standard.
Optional pneumatic wheels.

Order code:

TSHT4A

Frame dimensions (HxW):

1235 x 612 mm

Features:

Stair climber wheels for transporting over staircases.

Baseplate:

455 wide x 185 mm long

Load capacity:

220 kg

Wheels:

Stairclimber wheels and dolly wheels for easy steering of heavy load.
